Inlet manifold, 25mm bore straight back, overall height 88mm XS-35-1

Inlet manifold, 25mm bore straight back, overall height 88mm XS-35-1
  • Click to enlarge

£9.98 £8.32 ExVAT


Product Code: 6643

Inlet manifold, 25mm bore straight back, overall height 88mm XS-35-1

Tips forwards 10 degrees if held on the flat, most engines tip up 5 degrees

Manifold to head flange bolt centres 45mm M6 hole

Manifold to carburettor flange 48mm bolt centres M6 holes, Holes sit above centre line “Honda style”

Supplied with heat spacer and gaskets to suit, please note spacer and gasket sizes don’t always match 100% to manifold bore size.

Cast alloy

Product Code 6643
Condition New
Weight 0.1Kg
