Inlet manifold, 19mm bore straight back, overall height 81mm TB43-3

Inlet manifold, 19mm bore straight back, overall height 81mm TB43-3
  • Click to enlarge

£9.98 £8.32 ExVAT


Product Code: 6641

Inlet manifold, 19mm bore straight back, overall height 81mm TB43-3

Tips forwards 20 degrees if held on the flat, most engines tip up 5 degrees

Manifold to head flange bolt centres 45mm M6 hole

Manifold to carburettor flange 48mm bolt centres M6 holes, Holes sit above centre line “Honda style”

Supplied with heat spacer and gaskets to suit, please note spacer and gasket sizes don’t always match 100% to manifold bore size.

Cast alloy

Product Code 6641
Condition New
Weight 0.1Kg
